The FiberPlex SFX-10DD Data Diode provides a unidirectional network connection with 10-gigabit optics. Featuring data-diode functionality, the hardware modules transmit data in one direction with no return path. There is only one optical opening to connect a single fiber. The SFX-10DD modules are high performance, cyber secure modules supporting a host of data rates and distances. Patton's FiberPlex Cyber-SFP Modules are compatible with the small form-factor pluggable (SFP) multi-source agreement (MSA). They are RoHS compliant and lead-free. These optical modules are designed for digital data applications, and are not recommended for digital video applications due to SMPTE encoding that may cause pathological signal errors.
Core Features:
- CYBER (Data Diode)
- RX:1310nm
- Singlemode LC
- 10GB (OC192)
- 10km
- Single direction with no possibility for a return path
- Hot-pluggable SFP footprint
- RoHS compliant and Lead Free
- Milled Brass enclosure for maximum EMI/RFI containment and durability
- Single +3.3V power supply
- Low power dissipation <800mW
- SFP MSA SFF-8074i Compliant.
- Designed and Manufactured in the USA: Top notch quality and reliability with local support.
