Patton FiberPlex TKIT-12G/1CH/EUI 12G SDI Fiber Converter/Extender Kits

The FiberPlex TKIT-12G/1CH/EUI is a single‑channel 12G‑SDI to singlemode fiber converter designed for long‑haul, broadcast‑quality video transport. It supports bi‑directional transmission of one 12G/6G/3G/HD/SD‑SDI signal over two fiber strands, or uni‑directional transport over a single fiber at 1310nm up to 20km. Used in matched pairs, this video‑optimized solution includes AC power adapters and is ideal for flexible, throw‑down SDI fiber deployments.

Core Features:

• 12G-SDI Video to Singlemode Optical Conversion
• Single Channel
• Video Optimized
• 1310nm, LC, 20km
• Supports support a single channel of 12G-SDI in each direction (1-channel, bi-directional)
  over two strands of fiber or one channel of 12G-SDI in uni-directional over one fiber.
• Used in pairs for 12G SDI Fiber Transport
• Includes AC Power Adapters
